High-Rigidity CNC Machine for Heavy-Duty Roll MachiningCK84100 CNC Roller Lathe

Price 1.0 USD ($)/ Unit

Get a Price/Quote

MOQ : 1 Unit

About High-Rigidity CNC Machine for Heavy-Duty Roll MachiningCK84100 CNC Roller Lathe

Overview

The CK84100 CNC Roll Lathe is a heavy-duty, high-precision machine tool designed for machining large, heavy rolls and cylindrical parts. Built with advanced European-inspired design principles, it combines mechanical, electrical, and hydraulic technologies to deliver exceptional rigidity, stability, and performance for both rough and finish machining operations.

It is widely used in the machinery manufacturing industry for processing planes, curved surfaces, holes, and rotary parts, including outer circles, end faces, grooves, and profiles on rolls and similar components.

Core Features

High-Rigidity Structure

Three-way modular design with a heavy-duty four-rail bed ensures exceptional rigidity, vibration resistance, and long-term precision retention, even under heavy cutting loads.

Advanced & Reliable Performance

Adopts proven European design and process technology, with a standardized, interchangeable component structure. The machine offers reliable performance, easy operation, and low maintenance requirements.

Multi-Process Machining

Supports three-axis linkage (longitudinal, cross, and radial motion) for a wide range of operations, including turning, milling, boring, drilling, rigid tapping, reaming, and countersinking.

Superior Machining Quality

Achieves high precision up to IT6IT7 and surface roughness down to Ra0.8 m, meeting the requirements for precision parts and high-quality roll finishing.

Technical Specifications

Parameter	CK84100
Max Swing Diameter	1000 mm
Max Turning Diameter	1000 mm
Max Workpiece Length	5000 / 6000 / 8000 mm
Max Turning Length	5000 / 6000 / 8000 mm
Machine Guide Rail Width	1350 mm
Bed Rail Form	Four guide rails
Max Machine Loading Weight	20 T
X Axis Stroke	500 mm
Z Axis Stroke	5050 / 6050 / 8050 mm
X/Z Axis Movement Speed	3000 / 6000 mm/min
X/Z Axis Minimum Feed Amount	0.001 mm
Spindle Rotary Speed (Stepless)	4200 rpm
Spindle Top Code	A2-15 or 1:30 Long Cone
Spindle Bore	100 mm
Spindle Front End Taper	Metric 140
Spindle Top Taper	MT-6
Chuck	1000 mm
Cutter Shank Section	5050 mm
Tailstock Sleeve Diameter	300 mm
Tailstock Sleeve Stroke	300 mm
Tailstock Sleeve Cone Taper	100 (1:7)
Spindle Power	AC 75 kW
Working Accuracy	IT6IT7
Workpiece Surface Roughness	Ra0.8 m

Typical Applications

Machining of large rolls (fat rolls, hole-shaped rolls, etc.)
Turning of heavy-duty cylindrical parts and shafts
Processing of outer circles, end faces, grooves, and rotary surfaces
Rough and finish machining of complex components in the machinery, metallurgy, and steel industries
